FIND YOUR PART NUMBER

Min Max Min Max
Size (in) (in) (mm) (mm) Ideal 56 -0 Tridon 500 Ideal 58-0 Tridon 550
12 1/2 1-1/4 13 32 56120 500-012 5812 -
20 3/4 1-3/4 19 44 56200 500-020 5820 550-020
24 1-1/16 2 27 51 56240 - 5824 -
28 1 2-1/4 26 57 56280 - 5828 550-028
36 1 2-3/4 26 70 56360 500-036 5836 550-036
48 1-1/2 3-1/2 39 89 56480 500-048 5848 550-048
56 1 4 25 102 56560 500-056 5856 550-056
72 2 5 51 127 56720 500-072 5872 550-072
88 2-1/16 6 52 152 56880 500-088 5888 550-088
96 3-1/2 6-1/2 89 167 - 500-096 - 550-096
104 2-7/8 7 73 178 56104 500-104 58104 550-104
116 1-3/4 7-3/4 45 197 56116 500-116 58116 550-116
128 1-3/4 8-1/2 45 216 56128 500-128 58128 550-128
136 1-3/4 9 45 228 56136 - 58136 550-136
152 2 10 51 254 56152 500-152 58152 550-152
188 2 12-1/4 51 311 56188 500-188 58188 550-188
216 10-3/16 14 259 356 - 500-216 - 550-216
224 2-1/2 14-1/4 64 362 - - 58224 550-224
232 13-1/8 15 333 381 56232 500-232 - -
248 1-3/4 16 44 406 - 500-248 - 550-248
258 1-15/16 16-1/4 50 413 56258 500-258 - -
272 2-1/16 17 52 432 56272 - - -
280 14-1/4 18 362 457 - 500-280 - 550-280
288 1-13/16 18-1/2 45 470 56288 - - -
294 1-7/8 18-3/4 48 479 - 500-294 - -
312 1-7/8 20 48 508 - 500-312 - 550-312
332 2-1/16 21-1/4 53 540 56332 - 58332 -
344 1-3/4 22 44 559 - 500-344 - 550-344
390 18-5/8 25 473 635 - - - 550-390

No-Hub Couplings

Ideal Clamp Products, Inc. manufactures no-hub couplings that are listed or certified by all major
plumbing code bodies throughout U.S. and Canada. Visit www.idealtridon.com for more information.

• Classic
• Standard
• Heavy-Duty Yellow
• Super Heavy-Duty
• 12" and 15"
• Heavy-Duty Pow'r-Gear Red
